High Speed Custom Automatic Intelligent Barrier Gate with CE Approved 120W
Quick Detail:
Name: Intelligent barrier gate
Speed: 0.6s, 1s, 1.8s, 3s, 6s
Feature:Straight boom
Rated Power:120W
Certificate: CE, SGS
Net Weight: 50KG
Voltage:AC220V, AC110V
Functions & Features
1. Manual release
2. Machine core with compression spring, effectively avoids the accidents caused by spring
breaking
3. Die-casting aluminum alloy motor, precision and good at thermal radiating
4. Motor cooling fan, solving the problem of heat-protection
5. Double safety limit switches (photoelectricity limit switch/motor memory sensor)
6. Reversing on obstacle
7. Auto-closing
8. Support the INFRARER PHTOCELL for anti-bumping function (optional)
9. Support the external and internal VEHICLE LOOP DETECTOR (optional)
10. Traffic light interface
11. Wire control (switch signal)/ Remote control (418MHZ)
12. RS485 communication module (optional)
Techinical data:
| Type |
MX-60 |
| Operation time |
0.6s, 1s, 1.8s, 3s, 6s. Customized
|
| Arm Type |
Straight Arm: Max 6 meters, Size 45×100mm and 45*80 mm aluminum alloy
Fence Arm: Two or three fence arm, Max 6 meters, aluminum alloy
|
| Material |
Galvanized plate or Cold roll plate, 2mm thickness sheet
3 years without rust, shedding and fading
|
| Size |
320*280*935 mm
|
| Spring And Bearing |
Heat Treatment: more durable, more than 5 million times through operation testing
|
| Rating Power |
120W
|
| Rating Voltage |
AC 220V/110V±10%, 50/60HZ
|
| Remote Control Distance |
Usually more than 30 meters, if there is less obstacles, even 50 meters
or more
|
| G.W |
50 KG
|
| Delivery |
By Sea: big order(more than 100 sets), Cheap, suggested
By Air: small order(1-15 sets), quick and cheap, suggested
|
| Advantages |
1. Professional Manfacturer for more 8 years
2. Mould Production, High Accuracy
3. Heat Treatment, more durable than normal
4. Better Service from Professional Work Team
|
Parking & Shipping:
1. Strong carton case with cushion for safety, air bubble film inside for protect ing the apperance
from damaging.
2. As for wooden crate packing, it is USD$ 10/ps; for wooden case packing, it is USD$ 32/ps.
3. As for shipping, we can send you the goods by air, sea and express, which according to your
detail requirements.
Each barrier gate will include:
| 1 pcs Gate Barrier |
| 1 pcs arm boom (from 1m to 6m can customised) |
| 1 pcs control panel(built inside) |
| 2 pcs remote controllers |
| 1 pcs manual book |
Best Service:
Service for free:
1. One year free service is supplied(not including the arm)
2. Lifetime charged service is supplied
3. Technical service is supplied
4. OEM: we can customized machine case, color, logo for you, which accroding to
your detailed requirements.
5. Technical support and aftersales service, it is a long term relatioship between us.
6. Price can be negotiable when you have big order quantity.
Service for charging:
1. Broken by wrong installation
2. Broken by improper voltage
3. The surfaces of the barrier destroyed by wrong installation and usage
4. Overdue service items are out of our promise.
